Danfoss Randall TP5000 SI Wireless Programmable Room Thermostat
Danfoss RX1 Wireless RF Receiver included
Danfoss Randall RMT230 (230V) Electro-Mechanical Room Thermostat
RET2000B-RF Digital Room Thermostat and RX1-S Single Channel Receiver provide installation convenience and location flexibility for your home heating control. This is combined with
sleek modern design and high performing energy saving control in a feature packed RF thermostat. Incorporating a generous, easy to read display that clearly shows the room temperature and output status of the thermostat and bright status indicators on the receiver. The backlit display is ideal for those with poorer eyesight or in locations which are dimly lit. As well as standard on/off control the user can select to benefit from Danfoss chronoproportional control. Normally set at installation although easy to change via a DIP switch this micro-processor based control system will deliver increased comfort and improved economy. When chrono-proportional mode is set, the thermostat introduces a fixed cycle rate on the system and then determines the duration of the On and Off periods within each cycle in proportion to load. The control algorithm used to determine the on/off periods uses a proportional + integral (PI) routine to eliminate offset normally associated with on/off or simple proportional control. Chrono-proportional control significantly improves comfort and generally improves boiler efficiency by optimising water temperature. The RET2000B-RF includes an input for a remote sensor. Configurable for either a remote air temperature sensor, floor limit sensor or window
switch providing further control flexibility.
Additional features include settable upper and lower temperature limits as well as pushbutton lock to avoid tampering. If preferred the temperature display can also be set to show in F.
The RET2000B-RF also has the option to be set as a cooling thermostat, reversing the output logic and including compressor delay settings.
• Selectable Chrono Proportional or On/Off control
• User Set Upper and Lower Temperature Limits
• Output On Indication
• Remote Sensor Input
• Push Button Lock
• Cooling Option with Compressor delay
• °C or °F Selectable Display
Danfoss Randall TP5000 SI Programmable Room Thermostat
